Section
7.2
7-4 A38E Work Platform
Illustrated Parts Breakdown
CHASSIS ASSEMBLY A38E -
500202-000
ITEM PART NO. DESCRIPTION QTY.
1 514031-000 A38E CHASSIS WELDMENT 1
2 500232-000 A38E DRIVE MOTOR COVER 1
3 500233-000 A38E CHASSIS BODY COVER 1
4 500231-000 A38E MODULE COVER 2
5 500052-000 GRAB HANDLE 6
6 057727-000 TWIST SCREW FASTNER 4
7 500259-000 A38 COVER GRIP LATCH 4
8 500261-000 A38E MANIFOLD BLOCK 1
9 500260-000 A38E HYDRAULIC RESERVOIR ASSY
10 057532-000 RESERVOIR RETURN LINE FILTER ASSEMBLY(Inc Filter)
11
05
8074-000 FILTER / WASHER / SPRING ASSEMBLY (Part of item 10) 1
12
514274-000
DRIVE MOTOR (SN:006282 - 006522)
13
14
15
16
17 057530-000 MOTOR/PUMP ASSEM
BLY 1
18 057578-000 REAR WHEEL
NUT - M14 10
19 057
668-001 REAR WHEEL TYRE & RIM ASSY
20 057667
-003 FRONT WHEEL TYRE & RIM ASSY
21 056066-016 10
22 057669-000 STEERING STUB AXLE ASSY 2
23 058427-000 A38E TORQUE ARMS 2
24 500253-001 A38E STEERING LINKAGE PIN 4
* 500252-000 CIRCLIP 16mm 4
* 500408-000 BUSHINGS 2
25 500250-000 A38E STEERING LINK ARM 2
26 058463-000 A
38E STEERING CYLINDER 1
*
058494-035 MOUNTING BOLTS M12 4
* 056021-012 SPRING WASHER 4
27 0260021 CHARGER 240/100 VAC 50/60Hz
28 501868
-001 HORN 1
29 500234-002 A38E CHASSIS SIDE DROP PANEL
WITH SLOTS
30 501074-000 BATTERY 6V 210AH 8
010154-000 TERMINAL COVERS 18
31
32 ─ Please see page 7-6 ─
33 500234-001 A38E CHA
SSIS SIDE DROP PANEL
WITHOUT SLOTS
34 057580-000 DRIVE GEARBOX 2
FRONT WHEEL NUT - M16
------
512944-000
------
------
------
------
------
--------------------------------
--------------------------------
--------------------------------
12
------
--------------------------------------
DRIVE MOTOR (SN:006001 - 006281 / 006523 - ######))
------
--------------------------------------
1
1
2
2
2
2
1
1
1
057534-000 FILLER / BREATHER CAP 1
10a
