Section
7.2
7-6 A38E Work Platform
Illustrated Parts Breakdown
2
1
6
4 3 5
A38E PG PART ASSEMBLY -
ITEM PART NO. DESCRIPTION QTY.
1 512941-000 GP400 ECU 1
2 512943-000 PUMP MOTOR CONTROLLER 1
3 502588-000 ALARM SOUNDER 1
3 512684-000 ALARM BRACKET 1
4 513550-000 CONTACTOR SPDT 200A 12VDC 1
5 501877-000 FUSE HOLDER 1
5 067387-000 FUSE 1
6 512942-000 SEM600 MOTOR CONTROLLER 1
To Next Page
