Snorkel A38E - Page 86

Section
7.2
7-8 A38E Work Platform
Illustrated Parts Breakdown
BOOMS & POSTS ASSEMBLY
500201-000
ITEM PART NO. DESCRIPTION QTY.
1 058412-000 A38E FIRST POST WELDMENT 1
2 512614-000 BALLAST ASSEMBLY CE 1
* 512614-001 BALLAST ASSEMBLY ANSI 1
3 058417-000 A38E TENSION BAR WELDMENT 2
4 058416-000 A38E SECOND POST WELDMENT 1
5 058413-000 A38E LOWER BOOM WELDMENT 1
6 058414-001 OUTER TELE BOOM WELDMENT 1
* 260297 WEAR PAD 1-3/4" -4 ACME THREAD 2
7 058415-001 INNER TELESCOPIC BOOM WELDMENT 1
8 058457-002 A38E HOSE CABLE COVER 1
9 500265-000 COVER FOR ENERGY CHAIN CHANNEL 1
* 057727
-000 TWIST SCREW FASTENER 2
10 500266-000 ENERGY CHAIN SUPPORT CHANNEL 1
11 500468-000 ENERGY CHAIN - COMPLETE 1
* 500468-002 ENERGY CHAIN (1 UNIT OF 24) 24
* 500468-001 MOUNTING ELEMENTS 1
12 057975-000 INNER TELESCOPIC BOOM WEAR PAD 2
* 058510-016 M8 X 16 CSK 6
* 058510-025 M8 X 25 CSK 2
13 500275-001 OUTER TELESCOPIC BOOM WEAR PAD 2
* 058491-010 M6 X 10 HEX 8
* 500519-006 1/4" T4 WASHER 8
* 057975-300 6mm INSERTS 8
14 504504-000 A38E LOWER LIFT CYLINDER 1
15 504505-000 A38E UPPER LIFT CYLINDER 1
16 058734-000 A38E MASTER LEVELLING CYLINDER 1
17 058735-000 A38E SLAVE LEVELLING CYLINDE
R 1
18 058461-000 A38E TELESCOPIC CYLINDER 1
19 058056-000 PIN LOCK PLATE 16
056060-016 BOLT M10 X 16 mm 16
056021-010 SPRING WASHER 10 mm 16
20 058055-006 PIN-LOWER & UPPER BOOM TO FIRST 3
& S
ECOND POST
21 058054-001 PIN - TENSION BARS 4
22 058066-001 PIN - LIFT CYLINDER ROD END 1
23 058066-007 PIN - UPPER LIFT CYLINDER BODY END 1
24 058053-004 PIN - MASTER CYLINDER ROD END 1
25 058053-005 PIN - MASTER CYLINDER BODY END 1
26 058065-006 PIN - TELE CYLINDER BODY END 1
27 500254-000 PIN - TELE CYLINDER ROD END 1
28 058053-001 PIN -
SLAVE CYLINDER BODY END 1
29 058065-005 PIN - SLAVE CYLINDER ROD END 1
30 058066-001 PIN - TELE
SCOPIC BOOM TO CAGE 1
31 057033-000 CIRCLIP 30mm 4
32 057047-000 BUSHING STRAIGHT 25mm 8
33 057054-000 BUSHING FLANGED 30mm 12
34 057046-000 BUSHING FLANGED 35mm 8
35 057034-000 CIRCLIP 25mm 4
36 501085-000 BOOM REST (BOLT ON) 1
SERIAL BREAK
2890 - 3144 : Part No: 058460-000
SERIAL BREAK
2890 - 3144 : Part No: 058462-000
3145 - Current : Part No: 504505-000
