Section
7.2
7-10 A38E Work Platform
Illustrated Parts Breakdown
CAGE & CRADLE ASSEMBLY(STANDARD)
057603-000
(501864-000 is not included as part of this assembly)
Note : Ensure that items 10 (M16
screw and drilled nut with pin) remain loose,
these are safety bolts.
(ANSI is Without Overload)
ITEM PART NO. DESCRIPTION QTY.
1 057521-003 CAGE RAIL ASSY 1
2 508931-000 DROP BAR ASSY 1
3 513563-000 CONTROL BOX MOUNTING PLATE 1
4 513433-002 A38E UPPER CONTROL BOX CE 1
* 513433-003 A38E UPPER CONTROL BOX ANSI 1
5 010076-000 MANUAL HOLDER 1
6 501970-000 A38E CAGE FLOOR WELDMENT 1
7 058251-
000 LADDER LOCKING LATCH 1
8 057347-001 LADDER 1
9 513160-000 OVERLOAD UNIT CE 1
* 513161-000 LOAD CELL HARNESS 1
* 509791-000 OVERLOAD UNIT ANSI 1
10 509595 -000 M16 BOLT + NUT CROSS DRILLED 2
11 056069-016 M16 WASHER 8
12 503101-045 M16 X 45 HEX HEAD SCREW 8
13 056069-016 M16 WASHER 4
14
15 501971-000 CAGE CRADLE WELDMENT 1
###### ###### #
