Page 6 - 20 SL26/30SL
LOWER CONTROL PANEL ASSEMBLY - CE
ILLUSTRATED PARTS LIST
ITEM PART DESCRIPTION QTY
1 514488-000 LCB weldment 1
2 510521-000 SW TGL SPDT ON -
(ON)
1
3 510522-000 SW TGL SPDT (ON)
OFF (ON)
1
4 514132-000 Boot 2
5 510542-000 Push button 2
6 3087803 EZcal display 1
7 512543-000 Keyswitch 3 position
stayput
1
8 510524-000 SW twist release E/
stop
1
9 514496-000 LCB front panel 1
10 505082-014 Button HD screw M5 x
14 LG
4
11 512366-000 4 way panel plug 2
12 514489-000 Overlay 1
13 514622-000 2 way connector
Deutsch DT04-2P-
L012
2
14 514626-000 4 way connector,
Deutsch DT04-4P-
L012
1
15 514624-000 Wedge, Deutsch W2P 2
16 509750-000 Wedge, Deutsch W4P 1
ITEM PART DESCRIPTION QTY
17 514627-000 8 way connector,
Deutsch DT04-8PA-
L012
1
18 514629-000 Wedge, Deutsch W8P 1
19 509743-000 12 way connector,
Deutsch DT04-12PA-
L012
4
20 509744-000 Wedge, Deutsch W12P 4
21 13485-05 GP400C ECU
SL26&30 software
1
22 510155-000 3 way panel plug 1
23 512817-000 15 way panel plug 4
24 512934-000 LED red 12 V 1
25 502588-000 Alarm, ECCO beeping
6-28 V DC
1
26 13485-03 PG trionics TBM 1
27 509755-000 Mate-N-Lock SCKT
contact
4
28 509741-000 Blade fuse holder 1
29 509740-002 10 AMP blade fuse 1
30 100338-013 Crimp pin Deutsch
0460-202-16141
48
31 501251-016 SBHCS M4 x .7 x 16
GR 10.9 black nish
4
32 056069-004 M4 at washer - grade
8
4
33 056066-004 M4 nylock nut - 8 4
Table 6-14: SL26/30SL - 514487-000
