© Trynex International 2009 L1040
7 — 11
Complete Drive Assembly Parts Breakdown
SP-575 – D6117 SP-1075 – D6175
2000 – Current
Key
D 6106
Transmission
Motor 12 Volt DC
Motor Cover
Drive Enclosure
1075 Power Cord
575 Power Cord
Auger
1/2” NPT Plastic nut
Plastic Push Fastener
1/4”-20 x 1/2” Hex Bolt Stainless
3/16 x 1-1/4” Detent Clevis Pin
#10-32 x 5/8 Serrated Flange Bolt
Motor Drive Coupler
D 6107
D 6109
D 6111
D 6115
D 6162
D 6122
D 6781
D 6467
D 6131
D 6398
D 6122
D 6232
1
1
1
1
1
1
1
1
6
4
1
2
1
D 6140
10” Injection Molded Spinner
5/16-18 x 3/8” Set Screw
D 6750
1
1
Part No.
Description
Qty.
To Next Page
