© Trynex International 2009 L1040
7 — 39
Drop Utility Mount Parts Breakdown
Model #DRM-175
.ytQ noitpircseD .oN traP yeK
2 rehsaW talF "2/1 9114 D
2 tuN kcoL-"2/1 0214 D
D 4121 3/8"-16x1 Hex Bolt 2
8 tuN kcoL-"8/3 4214 D
9 rehsaW talF "8/3 5214 D
D 4135 2 - 5/16" Hair Pin Clip 2
D 4136 5/8" x 5-1/2" Hitch Pin 2
D 6246 1/2" - 13 x 2-1/2" Hex Bolt 2
D 4318 3/8" Fender Washer 8
.ytQ noitpircseD .oN traP yeK
D 6420 3/8" - 16 x 2 Truss Bolt Full Thread 8
D 6421 3/8" - 16 Hex Nut 2
D 6422 3/8" - 16 x 5" Hex Bolt 1
D 6423 2'' Rubber Stopper 1
2 liaR gnitnuoM 2346 D
D 6434 Drop Mount Weldment 1
D 6435 Mounting Rail Hat Section 2
1 retpadA eluM 6346 D
Maximum Load Weight Not To Exceed 240 lbs. Gross
#3 & #17 Form Stop Type One
#11, 5, 13 & 12 Form Stop Type Two
To Next Page
