SnowEx Bulk-Pro 1875 - Adjustable Deflector

© Trynex International 2009 L1040
7 — 24
Adjustable Deector Parts Breakdown
Model #ADF-020 For SP-575 and SP-1075
.ytQ noitpircseD .oN traP yeK
1 D 4121 3/8'' - 13 x 1'' Hex Bolt
2 D 4124 3/8'' - Locknuts
3 D 4125 3/8'' - Flatwashers
4 D 6138 5/16'' - 18 Locknut
rotcelfeD ''63 4516 D 5
6 D 6166 5/16'' - 18 x 1'' Hex Bolt
7 D 6179 Deector Adjustment Bracket
8 D 6180 Adjustment Bar Mounting Bracket
9 D 6181 Adjustment Bar
2
2
2
10
1
10
1
2
2
Rev. 05
