© Trynex International 2009 L1040
7 — 26
Gate Assembly Kit Parts Breakdown
Model #GAK-020
for SP-575 and SP-1075
Key Part No. Description Qty.
D 4289 1/4'' Lock Nut
D 6138 5/16'' Lock Nut
D 6140 5/16'' Set Screw
D 6185 Agitation Auger
D 6365 SS Gate Body
D 6366 SS Gate Slide
bonK etaG 2036 D
D 6367 SS Throat Mount
elbaC '01 4036 D
D 6305 Cable Fitting Assy
D 6308 5/16'' - 18 Special Bolt
D 6309 Knob Square Nut
D 6311 1/4 - 20 x 1/2'' Hex Bolt
D 6368 SS Gate Stop Indicator
D 6351 Cable Mounting Bracket
2
1
GAK-020 Assembly
Bottom View
GAK-020 Assembly
Top View
1
1
1
1
1
1
1
1
1
1
2
1
1
To Next Page
