SnowEx Bulk-Pro 1875 - Page 30

© Trynex International 2009 L1040
7 — 30
Receiver Hitch Mount Parts Breakdown
Shown with SP-1075 conguration
Model #RHT-375
. ytQ
noitpircseD .oN traP
yeK
D 4116
41/2-13 X 1-1/2” Hex Bolt
D 4119
41/2” Flat Washer
D 4120
61/2” Lock Nut
D 4121
163/8-16 x 1” Hex Bolt
D 4124
243/8” Lock Nut
D 4135
12-5/16” Hair Pin Clip
D 4136
15/8” x 5-1/2” Hitch Pin
D 6270
12” Receiver Weldment
D 6503
2Ratchet Strap
D 6386
2Upper Rail Weldment
D 6387
2Lower Rail Weldment
D 6388
2Vertical Rail Support
D 6392
83/8-16 x 3” Tap Bolt
D 6791
21/2-13 x 2” Non-Skid Leveling Pad
Rev. 05
