© Trynex International 2009 L1040
7 — 33
Pivot Mount Parts Breakdown
Model #PMT-175
NOTE:
When installing the Pivot Mount, if any movement is
noted with Rail Brackets due to weakened or altered
conditions of pick-up bed, drill and bolt through
pre-punched Rail Brackets to assure rm mounting.
NOTE: See Installation Warning
(Packaged with Kit) Before Drilling Holes.
.ytQ noitpircseD
.oN traP
yeK
.ytQ noitpircseD
.oN traP
yeK
D 4116 1/2-13 x 1-1/2” Hex Bolt
1/2” Flat Washer
1/2” Lock Nut
3/8-16 x 1” Hex Bolt
3/8-16 x 1-1/2” Hex Bolt
3/8 Lock Nut
3/8 Flat Washer
5/16 Lock Nut
5/16-18 x 2” Hex Bolt
1/2” Toggle
1/2-13 x 3” Hex Bolt Full Thread
Bed Rail Bracket Right
Bed Rail Bracket Left
Pivot Tube Assembly
Angle Top
Pivot Bumper Bracket
Latch Bumper Bracket
Pivot Channel Assembly
Latch Channel Assembly
Rubber Tip Protector
2
7
5
16
13
29
9
1
1
2
4
1
1
1
1
1
1
2
2
4
D 4119
D 4120
D 4121
D 4122
D 4124
D 4125
D 6138
D 6139
D 6141
D 6144
D 6200
D 6201
D 6202
D 6203
D 6204
D 6205
D 6206
D 6207
D 6208
1/2-13 x 4” Hex Bolt Full Thread
1/8” x 2-1/16” Hair Pin Clip
2 2
D 6142
D 6222
1/2-13 x 1-1/4” Hex Bolt
Latch Bar
3 1
D 6143
D 6223
NOTE: Pay special attention when drilling or clamping dissimilar
metals to aluminum bodies. Galvanic corrosion can occur if not
handled properly. Contact vehicle manufacturer for recommended
attachment practices.
