© Trynex International 2009 L1040
7 — 37
Three-Point Mount Parts Breakdown
Model #TPM-175
CAUTION: MAXIMUM OF 240 LBS. GROSS WEIGHT CAN BE PUT ONTO MOUNT.
Key Part No. Description Qty.
D 4133 5/16” Linch Pin 2
D 4135 2-5/16” Hairpin Clip 1
D 4136 5/8” x 5-1/2” Hitch Pin 1
D 4137 7/8” x 5-1/2” Lift Arm Pin 2
D 6147 Three Point Frame 1
To Next Page
