2. Ten digits input keys, two functional keys: “#”, “
＊
”.
# key: Confirmation key.
＊
key: Clear or escape key.
Types of proximity cards
＊
The following 3 types of cards are require to undergo the registration
procedures on the reader unit before utilization.
SC-10 : Thin card , thickness 0.8 mm,
ISO standard card dimension.
Read range 25 cm. Can be printed
directly from card printer.
SC-20 : Thick card , thickness 1.8 mm,
ISO standard card dimension.
Read range 20 cm. Can be printed
directly from card printer.
SC-30 : Key tag, readrange 12cm.
dimension 5.5L X 7.5H X 3.2W (mm).
Ultrasonic connection, water-proof,
shock- proof.
1
3
2
4
6
8
0
_
#
9
7
5
X
12345678
P. 2
Power light (RED)
Deny light (YELLOW)
Oaky light (GREEN)
Status light (YELLOW)
Confirmation key
Clear or escape key
LCD display
with back-light
