Barcode Support
:
Symbologies
7C/7Ci: Bookland EAN (ISBN / EAN-13), Chinese 2 of 5, Codabar
(including support for ISBT 128 bit concatenation), Code 11, Code 128, Code 39,
Trioptic Code 39, Code 39 Full ASCII, Code 93, Discrete 2 of 5, GS1
DataBar (RSS), GS1-128 (UCC-128 / EAN-128), Interleaved 2 of 5
(ITF-14), Inverse 1D, Matrix 2 of 5, MSI, UPC / EAN / JAN, VIN
7E/7M/7P: Bookland EAN (ISBN / EAN-13), Chinese 2 of 5, Codabar
(including support for ISBT 128 bit concatenation), Code 11, Code 128, Code 39,
Trioptic Code 39, Code 39 Full ASCII, Code 93, Discrete 2 of 5, GS1
DataBar (RSS), GS1-128 (UCC-128 / EAN-128), Interleaved 2 of 5
(ITF-14), MSI, UPC / EAN / JAN, VIN
Scanning Barcodes on
Device Screens
Supported only by CHS 7C/7Ci
Scanner Performance:
Scanner Type
7C/7Ci: Linear Imager (1D)
7E: Class 1 linear laser (1D)
7M/7P: Class 2 linear laser (1D)
Scan Angle
7C/7Ci: 53.3 ±3°
7E/7M/7P: Wide (default): 47° ±3° Narrow: 35° ±3°
Scan Repetition
Rate
7C/7Ci: 50 scans/sec
7E/7M/7P: 100 scans/sec (bi-directional)
Optical Resolution
7C/7Ci: 5 mil minimum
7E/7M/7P: 0.004 inch (0.102 mm) min./barcode element width (X Dimension)
Print Contrast
7C: Minimum 20%
7E/7M/7P: Minimum 25% absolute dark/light reflectance (MRD) measured at
650 nm
Decode Distance
Depends on symbol
density, symbology,
W-N Ratio, label
media, and scan
angle
7C/7Ci: 2.25 to 20 inches (5.7 to 50.8 cm)
7E: 1.5 to 10.5 inches (3.8 to 27 cm) typical
7M/7P: 1.5 to 45+ inches (3.8 to 144+ cm) typical
Vibrate Mode
Supported only by 7P. Provides tactile feedback for good read.
Bluetooth Characteristics:
Interface
Standard
Bluetooth Human Interface Device (HID) and Serial Port Profile (SPP)
Default mode: HID Keyboard class device
Protocol
Bluetooth 2.1 with Enhanced Data Rates (EDR)
2.45 GHz ISM band, supports Advanced Frequency Hopping (AFH)
Radio Range
Up to 330 ft (100 m), depending on environment
Security
56 bit encryption
RF Power
Class 1 radio; Typical Output: 12 dbm
Bluetooth Stack
Support for
Windows & Mac
OS
Windows Mobile: Microsoft, Broadcom v1.8.0.6501 or v1.9.3
Windows PC: Microsoft, Toshiba 4.00.34, 5.00.6F or later, Broadcom
5.1.0.1700 or later (Bluetooth 2.1 for best results)
Mac OS: v2.2.4f3 (v1965)
Compatibility
Windows COM port
