Presentation
The product allows:
• sources control,
• automatic transfer control in AUT mode,
• parameters configuration,
• voltage and frequency metering,
• system state display,
• alarm or fault indication,
Controller ATyS
OPERATION
ATyS C40
42
SOCOMEC - Réf. : 532 929 B
Presentation
Operational modes
Programming
Operation
Visualisation
Automatic sequences
7 digits + 14 pointers
LCD
Green led is on when product is
powered
POWER led
Led is on when product is faulty.
Disconnect power supplies to reset
FAULT led
- Led is on: source = OK
- Led is off: source is not available
- Led is blinking: order to start is running
Sources state
2 green leds:
- switch I state
- switch II state
Switch state
- Active source: to force the next active source
- Partial counter reset
- Genset remote start (test of load)
Operational modes
Keypad
Escape Navigation
Validation
LCD & leds test
Operations
ATYS 469 A GB
