socomec ATyS C40 User Manual

Controller ATyS
CONNECTIONS
41
SOCOMEC - Réf. : 532 929 B
Control circuits
Denomination Terminals Description Characteristics Recommended
section
Power supply L3 (104) Phase 3 440 V ac (phase-phase) 1.5 mm
2
Source L1 (106) Phase 1 maximum, 50/ 60 Hz
Power supply L1 (203) Phase 1 440 V ac (phase-phase) 1.5 mm
2
Source L3 (205) Phase 3 maximum, 50/ 60 Hz
Power supply DC DC- Power supply 0 V From 9 V dc to 30 V dc 1.5 mm
2
12Vdc, 24Vdc DC+ Power supply + V dc maxi.
Genset 13 Genset start/ stop relay - 2 stable positions Dry contact 1.5 mm
2
start signal
(1)
14 Programmable state - factory setting = NO, close to start 5A AC1/250 V
Control 23 Impulse mode: order to close source 5 A AC1/ 250 V
(impulse, 24 Contactor mode: order to close contactor source
contactor Breaker mode: order to close breaker source
and breaker 33 Impulse mode: order to close source 5 A AC1/ 250 V 1.5 mm
2
mode to 34 Contactor mode: order to close contactor source
programm) Breaker mode: order to open breaker source
43 Impulse mode: order to close position 0 5 A AC1/ 250 V 1.5 mm
2
44 Contactor mode: programmable relay O1
Breaker mode: order to close breaker source
Genset 53 Genset start/ stop relay - 2 stable positions 5 A AC1/ 250 V 1.5 mm
2
start signal
(1)
54 Programmable state - factory setting = NO, close to start
Information 301 Auxiliary contact information position 1 CA1 Do not connect to 1.5 mm
2
auxiliary 302 Programmable input 3 any power supply
contacts 303 Auxiliary contact information position 2 CA2
Programmable 304 Programmable input 1 Do not connect to 1.5 mm
2
Inputs 305 Programmable input 2 any power supply
Common 316 Specifique voltage supply Do not connect to 1.5 mm
2
input Common terminals 301 to 310 any power supply
(1) Refer to programming, Setup, to modify relay state.
22
2
1
2
2
1
1
1
11
2
1
