socomec ATyS C40 User Manual

Controller ATyS
CONNECTIONS
39
SOCOMEC - Réf. : 532 929 B
Control circuits
400 Vac (P-P) APPLICATION WITH NEUTRAL CONDUCTOR
CONTACTOR TYPE TECHNOLOGY
I1I3 I2
F1, F2
Fuse protection
230 Vac 5 A
LOAD
III
O1
L1
L2
L3
N
L1
L2
L3
N
F2F1
K1
K1
K2
K1
K2
K2
13 14 23 24 33 34 43 44 53 54
+-
301 302 303 304 305 306 DC- DC+
103 205
L3
203
L1
106
L1
105104
L3
GE1
NL2
GE2
ATYS 468 B GB
• Configure the type of control logic in contactor (see
Programming chapter).
Maximum control cables lenght = 10 m.
In case of longer distance, insert control
relays.
