3.1. The ATyS Range Key Features
Selecting the right ATyS will depend on the application, the functionality required as well as the nature of the installation in
which the ATyS will be installed. Below is an outline product selection chart listing the key features of each product to help to
select the right ATyS for your needs.
IEC 60947-6-1
ATyS S ATyS Sd ATyS r ATyS d ATyS t ATyS g ATyS p
UL 1008
ATyS
Motorised Changeover with control driven by dry contacts
• • • • • • •
ManualEmergencyOperationwithexternalhandle
• • • • • • •
Wide band AC control voltage supply
• • • • • • •
WidebandDCcontrolvoltagesupply
•
Watchdog relay to ensure product availability
• • • • •
Ratings from 40 – 125A as indicated or 125A - 3200A for •
40 –
125A
40 –
125A
UL 100
– 400A
• • • •
Overridecontrolsandforceswitchtozero(off)position
• • • • •
Integratedpositionauxiliarycontacts(I-O-II)
• • • • • • •
SourceavailabilityLEDdisplay
• • • •
RemoteDisplaymoduleRJ45connectionforD10
• • •
IntegratedDualpowersupply
• • • • •
Network - Network Applications
• • • • • •
Network - Genset Applications
• • • • • •
Genset - Genset Applications
• • • •
Pre-definedfixedI/O
• 5/1 • 5/1 • 9/2 • 11/3 • 5/2
Programmable I/O
• 6/1
AdditionalprogrammableI/Omodules(Optionalupto4modules)
• 8/8
Remotely operated Transfer Switching Equipment
(RTSEClassPC)
• • • •
AutomaticTransferSwitchingEquipment(ATSEClassPC)
• • •
Remote + Manual Control
• • • •
Auto + Remote + Manual Control
• •
Auto + Remote + Local + Manual Control
•
Auto-configuration of voltage and frequency levels
• • •
SwitchPositionLEDdisplay
• • •
Security Sealing Cover
• •
Configuration through potentiometers and dip switches
• •
Test on load functionality
• •
Test off load functionality
• •
ProgrammableconfigurationwithkeypadandLCDdisplay
•
Metering & Measurement: kW; kVar; kVA + kWh; kVarh; kVAh
•
CommunicationRS485+Ethernet+Ethernetgateway(Optional)
• •
WebserverAccessthroughoptionalEthernetmodule(Optional)
•
EasyConfigurationsoftware(ThroughEthernet/Modbus)
•
RemoteTerminalUnitRJ45connectionforD20
•
DataLoggerforEventRecordingwithRTC
(ThroughEthernet/Modbus)
•
ProgrammableEngineExerciserfunctionality
(ThroughEthernet/Modbus)
•
Multi level password access
•
Load Shedding function
•
Capacity Management functionality
•
Peak shaving functionality
•
4-20mAcommunicationmodule(Optional)
•
KWhPulsedoutputmodule(Optional)
•
CountersKWh,permutation…
•
LCDdisplayforprogramming,metering,timersandcounters
•
Possibility to add optional functionality
•
