socomec ATyS r Quick Start Guide

ATyS r Assembling the motorisation module on the Power Section
Pos. = Pos.
125 -> 630 A = 3Nm
800 ->3200 A = 8Nm
5
3
1
2
4
ATyS d, t, g and p Assembling the motorisation & ATS Controller on the Power Section
Pos. = Pos.
125 -> 630 A = 3Nm
800 ->3200 A = 8Nm
ASSEMBLING / MONTAGE / MONTAJE
CORPORATE HQ CONTACT: SOCOMEC SAS, 1-4 RUE DE WESTHOUSE, 67235 BENFELD, FRANCE. Non contractual document.
1 2 3
4a 4b 5
1 2 3
4a 4b 5
