socomec ATyS Series User Manual

Transfer switches
atys_d_001_a_1_cat
atys_836_a_1_cat
ATyS r - ATyS d
Remotely operated Transfer Switching Equipment
from 125 to 3200 A
> Applications with an external
ATS/AMF controller
> Building Management
Systems (BMS)
The solution for
> Watchdog relay to check
product availability
> Integrated auxiliary contacts
> Extended power supply range
> ATyS d: integrated dual power
supply
Strong points
Function
ATyS r and ATyS d are three-phase remotely operated motorised transfer switches, 3 or 4
poles, with positive break indication.
They enable the on load transfer of two three-phase power supplies via remote volt-free
contacts, from either an external automatic controller, using pulse logic, or a switch.
They are intended for use in low voltage power systems where interruption of the load supply
is acceptable during transfer.
Advantages
Watchdog relay to check product
availability
ATyS r and ATyS d products are equipped
with a Watchdog relay which constantly
monitors your product, thereby securing the
installation.
This relay informs in real time the user of
the product's availability, i.e. whether it is
operational and ready for source switching.
Integrated auxiliary contacts
As part of the product monitoring function, the
ATyS r and ATyS d enable the transmission
of information relating to their position. This is
possible thanks to the standard integration of
an auxiliary contact for each position.
Extended power supply range
ATyS r and ATyS d products offer greater
availability thanks to their extensive power
supply range of 208 to 277 VAC ± 20%.
ATyS d: integrated dual power supply
In addition to the functions offered by the
ATyS r, the ATyS d incorporates supply
redundancy without the need for additional
wiring. This is obtained by integrating a double
supply (2independent power supplies) directly
within the product.
> IEC 60947-6-1
> IEC 60947-3
Conformity to standards
> The ATyS r and ATyS d
are compatible with our
ATySC30 external controllers
(for mains/mains and mains/
genset applications) and
ATySC40 controllers
(for genset/genset
applications).
External automatic controller
ATyS r - ATyS d
Remotely operated Transfer Switching Equipment
from 125 to 3200 A
References
Rating (A) /
Frame size No. of poles ATyS r ATyS d Bridging bars
Terminal
shrouds
Terminal
screens
Auxiliary
contact
3 position
padlocking
Auto
transformer
125 A / B3
3 P
9523 3012 9533 3012
3 P
4109 3019
4 P
4109 4019
3 P
2694 3014
(2)
4 P
2694 4014
(2)
3 P
1509 3012
4 P
1509 4012
1599 0002
(4)
9599 0003
(4)
400/230 VAC
1599 4064
4 P
9523 4012 9533 4012
160 A / B3
3 P
9523 3016 9533 3016
4 P
9523 4016 9533 4016
200 A / B3
3 P
9523 3020 9533 3020
4 P
9523 4020 9533 4020
250 A / B4
3 P
9523 3025 9533 3025
3 P
4109 3025
4 P
4109 4025
3 P
2694 3021
(2)
4 P
2694 4021
(2)
3 P
1509 3025
4 P
1509 4025
4 P
9523 4025 9533 4025
315 A / B4
3 P
9523 3031 9533 3031
3 P
4109 3039
4 P
4109 4039
4 P
9523 4031 9533 4031
400 A / B4
3 P
9523 3040 9533 3040
4 P
9523 4040 9533 4040
500 A / B5
3 P
9523 3050 9533 3050
3 P
4109 3050
4 P
4109 4050
3 P
2694 3051
(2)
4 P
2694 4051
(2)
3 P
1509 3063
(3)
4 P
1509 4063
(3)
4 P
9523 4050 9533 4050
630 A / B5
3 P
9523 3063 9533 3063
3 P
4109 3063
4 P
4109 4063
4 P
9523 4063 9533 4063
800 A / B6
3 P
9523 3080 9533 3080
3 P
4109 3080
4 P
4109 4080
3 P
1509 3080
(3)
4 P
1509 4080
(3)
1599 0032
(4)
9599 0004
(4)
4 P
9523 4080 9533 4080
1000 A / B6
3 P
9523 3100 9533 3100
4 P
9523 4100 9533 4100
1250 A / B6
3 P
9523 3120 9533 3120
3 P
4109 3120
4 P
4109 4120
4 P
9523 4120 9533 4120
1600 A / B7
3 P
9523 3160 9533 3160
3 P
4109 3160
4 P
4109 4160
3 P
1509 3160
(3)
4 P
1509 4160
(3)
4 P
9523 4160 9533 4160
2000 A / B8
3 P
9523 3200 9533 3200
(1)
3 P
1509 3200
(3)
4 P
1509 4200
(3)
included
4 P
9523 4200 9533 4200
2500 A / B8
3 P
9523 3250 9533 3250
4 P
9523 4250 9533 4250
3200 A / B8
3 P
9523 3320 9533 3320
4 P
9523 4320 9533 4320
> Accessories: see
> Characteristics: see
> Terminals and connections: see
> Dimensions: see
Technical information
(1) See "Copper bar connection kits" page
(2) To fully shroud front, rear, top and bottom 4 references required.
To shroud front switch top and bottom 2 references required.
(3) 2 pieces: one for top side and another for bottom side.
(4) Factory mounting only.
page 71.
page 70.
page 76.
page 78.
page 80.
63
Changeover Switching solutions - Catalogue 2015

socomec ATyS Series Specifications

General

Type	Automatic Transfer Switch (ATS)
Transfer Mode	Open or closed transition
Control	Automatic, Manual, Remote
Standards	IEC 60947-6-1
Communication	Modbus, Ethernet
Protection Degree	IP20
Poles	3 or 4 poles
