socomec COUNTIS E24 User Manual

29EN
COUNTIS E23/E24 - 545877A - SOCOMEC
TARIFF for Ea+
Tariff management Yes (via input and communication)
Number of tariffs managed 2
Tariff input Yes
Input type Opto-isolated
Voltage
0V --> Tariff 1
80-276VAC-DC --> Tariff 2
METROLOGICAL LED (Ea+, Ea-)
Pulse value 1000 pulses / kWh
Colour Red
PULSE OUTPUT
Type Opto-isolated - 5 … 27VDC 27mA according to EN62053-31
Pulse weight 100 Wh
DISPLAY
Type 8-digit LCD with backlight
Refresh time 1s
Backlight activation time 10s
Active energy: 1 display, 8-digit 000000.01 - 999999.99 kWh
Reactive energy: 1 display, 8-digit 000000.01 - 999999.99 kvarh
Apparent energy: 1 display, 8-digit 000000.01 - 999999.99 kVAh
Realtime active power: 1 display, 4-digit 00.00 - 99.99 kW
Realtime reactive power: 1 display, 4-digit 00.00 - 99.99 kvar
Realtime reactive power: 1 display, 4-digit 00.00 ... 99.99 kVA
Realtimevoltage: 1 display, 4-digit 000.0 ... 999.9 V
Realtime current: 1 display, 4-digit 00.00 ... 99.99 A
Power factor: 1 display, 4-digit 0.001-1.000
Frequency: 1 display, 4-digit 45.00-65.00 Hz
COMMUNICATION
RS485 2 wires + shielding/ half duplex
Protocol Modbus, RTU mode
Baudrate 1200 / 2400 / 4800 / 9600 / 19200 / 38400 / 57600 / 115200 bps
Insulation SELV
Load unit 1/8
SAVING
Energy registers In FRAM memory
ENVIRONMENTAL CONDITIONS
Mechanical environment M1
Electromagnetic environment E2
Operating temperature range -25°C to +55°C
Storage temperature -25°C to 75°C
Humidity ≤80%
Installation Internal (box/cabinet)
Vibrations ±0.075 mm
