ENERGY ACCURACY
Active energy Ea+
Class C (EN 50470-3)
Class 1 (EN 62053-21)
Reactive energy Er+ Class 2 (EN 62053-23)
TARIFF for Ea+
Tariff management Yes (via communication)
Number of tariffs managed 4 (via communication)
METROLOGICAL LED (Ea+, Ea-)
Pulse value 1000 pulses / kWh
Colour Red
PULSE OUTPUT
Type Opto-isolated - 5 … 27VDC 27mA according to EN62053-31
Pulse weight according to the set CT ratio
1 Wh à CT -> 1 ... 4
5 Wh à CT -> 5 ... 24
25 Wh à CT -> 25 ... 124
125 Wh à CT -> 125 ... 624
1000 Wh à CT -> 625 ... 3124
10000 Wh à CT -> 3125 ... 12000
DISPLAY
Type 8-digit LCD with backlight
Refresh time 1s
Backlight activation time 10s
Active energy: 1 display, 8-digit 00000.000 kWh ... 999999.99 MWh
Reactive energy: 1 display, 8-digit 00000.000 kvarh ... 999999.99 Mvarh
Apparent energy: 1 display, 8-digit 00000.000 kVAh … 999999.99 MVAh
Instantaneous active power: 1 display, 4-digit 0.000 kW ... 99.99 MW
Instantaneous reactive power: 1 display, 4-digit 0.000 kvar ... 99.99 Mvar
Instantaneous apparent power: 1 display, 4-digit 0.000 kVA ... 99.99 MVA
Intantaneous voltage: 1 display, 4-digit 000.0 ... 999.9 V
Intantaneous current: 1 display, 4-digit 0.000 ... 99.99 kA
Power factor: 1 display, 4-digit 0.000 … 1.000
Frequency: 1 display, 4-digit 45.00-65.00 Hz
COMMUNICATION
Ethernet Full duplex
Protocol Modbus TCP, HTTP, NTP, DHCP
Baudrate 10/100 Mbps
Web server password
Username: admin / password: Admin
Username: user / password: user
Default IP address
Default Gateway IP address
Default netmask
Default slave address
192.168.0.4
192.168.0.1
255.255.255.000
5
SAVING
Energy registers In FRAM memory
