GB
DIRIS A40/A41 - RS485 - JBUS/MODBUS
®
5
DIRIS A40/A41 - Ref.: 536 103 B GB
CONNECTION
ThemoduleisttedontothebackoftheDIRIS A40/A41 in one of the 4 positions provided.
DIRIS 342 A
1
NO
1
DIRIS 347 A
3
DIRIS 343 A
2
Fix the module in one of the four positions.
4
Follow indications when connecting the terminal.
Switch on voltage supply.
INSTALLATION
The DIRIS A40/A41 must be switched off
