19
EN
DIRIS B 546 770 A - SOCOMEC
5. MOUNTING
3GDENKKNVHMFO@Q@FQ@OGRCDRBQHADSGDHMRS@KK@SHNMNESGD#(1(2Ű!SGDNOSHNM@KLNCTKDR@MCSGD@RRNBH@SDCRDMRNQR
5.1. Recommendations and safety
1DEDQSNSGDR@EDSXHMRSQTBSHNMRRDBSHNMf'@Y@QCR@MCV@QMHMFRtO@FD
5.2. Installing the DIRIS B
5.2.1. DIN rail mounting
Mounting Removal
1
2
0.29 or 0.59
7.5 or 15
1.38
35
1 2
5.2.2. Plate mounting
0.19 in
5 mm
3.94 in
100 mm
Type of screw: M4
Tightening torque: 0.5 Nm
Washer: maximum diameter
0.47in/12mm
