15EN
4.6.1. TE solid-core current sensors
4.6.1.1. Range
TE-18 TE-18 TE-25 TE-35 TE-45 TE-55
Pitch
I nominal
63A
Maximum l
24A 192A
Reference
4.6.1.2. Dimensions
L
P
W
H
L
W
P
T
H
Dimensions in
TE-18 TE-25 TE-35 TE-45 TE-55
Pitch
0.71
0.98
1.37
1.77
2.16
LxHxD
1.10 x 0.79 x 1.77
0.98 x 1.28 x 2.56
1.37 x 1.28 x 2.79
1.77 x 1.28 x 3.38
2.16 x 1.28 x 3.93
Window (W)
ø 0.33
0.53 x 0.53
0.82 x 0.82
1.22 x 1.22
1.61 x 1.61
(T)
0.69
0.69
0.77
0.85
