LOAD
|
I-30@4 ID:FOC1D2
INPUT I01 I02 I03
CT 250 A 250 A 250 A
WAY +/DIRECT +/DIRECT +/DIRECT
LINE V V3 V2 V1
LOAD L1 L1 L1
TYPE 3P+N_3CT 3P+N_3CT 3P+N_3CT
PRESS OK TO ENTER SETTINGS
The 3 current inputs I01, I02, I03 are assigned to the same three-phase load no. 1 (L1).
LOAD
|
I-30@4 ID:FOC1D2
INPUT I01 I02 I03
CT 250 A 250 A 250 A
WAY +/DIRECT +/DIRECT +/DIRECT
LINE V V3 V2 V1
LOAD L1 L1 L1
TYPE 3P+N_3CT 3P+N_3CT 3P+N_3CT
PRESS OK TO ENTER SETTINGS
The “CT” eld indicates the current rating of the sensor connected and the “WAY” eld shows if it was mounted
inthecorrect orientation (+/DIRECT = P1 --> P2) or backwards (-/INV = P2 --> P1)
LOAD
|
I-30@4 ID:FOC1D2
INPUT I01 I02 I03
CT 250 A 250 A 250 A
WAY +/DIRECT +/DIRECT +/DIRECT
LINE V V3 V2 V1
LOAD L1 L1 L1
TYPE 3P+N_3CT 3P+N_3CT 3P+N_3CT
PRESS OK TO ENTER SETTINGS
