14. DIRIS DIGIWARE M-50/M-70 TECHNICAL
CHARACTERISTICS
14.1. Mechanical characteristics
Weight DIRIS Digiware M-50 / M-70 210 g
14.2. Communication characteristics
Default Ethernet settings - IP address: 192.168.0.4
- Mask: 255.255.255.0
- Gateway: 192.168.0.1
Maximum slave devices 32
Ethernet RJ45 10/100 Mbs Gateway function:
- MODBUS TCP / RTU
- BACNET IP
- SNMP v1, v2 & v3
Embedded software Web-Config (M-50/M-70) for configuration of M-50/M-70.
WEBVIEW-M (M-70 only) for visualization of measurement data.
SNTP Updates the M-50/M-70 from an SNTP server.
The M-50/M-70 updates the connected devices.
SMTP(S) Sends email notifications in case of an alarm on a downstream device.
FTP(S) Automatically exports data to an FTP server (standard or secure FTP):
Energies Index, load curves (Powers), Trends (measurement logs).
RJ45 Digiware Control and power supply interface function.
RS485 2-3 wires 1 port, configured as Input (Master) or Output (slave).
Speed 9600 bds (10 devices max).
38400 bds - 115200 bds (32 devices max).
Micro USB For configuration via EasyConfig System software or firmware upgrade via Product
Upgrade Tool.
RJ9 Not used.
Bluetooth Low Energy
Use: feature not implemented yet.
Operating frequency: 2402 to 2480 MHz.
EIRP Power: 6.23 dBm (measured max. average).
14.3. Electrical characteristics
Power supply 24 VDC +/- 10%
Power consumption 2.5 VA
Battery life 10 years with the following typical battery profile over its lifetime:
- Product storage: 1 year of full time battery back-up (based on an average storage
temperature of 25°C).
- Product life: 10 days / year of battery back-up over 9 years.
Battery type 3V Lithium cell battery, 48mAh rated capacity.
