socomec DIRIS Digiware M-50 - Page 52

52 EN
DIRIS Digiware M-50 & M-70 - 548751B - SOCOMEC
The table with indexes of the analog input measurement list is given below:
Index Object Namew Object Description Unit Type Present + Timestamp Present Min/Max + Timestamp Average + Timestamp Average Min/Max + Timestamp Harmonics 2 -> 10 Energies Total + Partial + LastPartial Energies Total Lagging/Leading Multifluid Reset Min/Max
0 VystPhN System Ph-N
Voltage
V Unsigned
• •
1 VystPhPh System Ph-Ph
Voltage
V
Unsigned
• •
2 CurrentSyst System Current A
Unsigned
• •
3 Frequency System
Frequency
Hz
Unsigned
• • • • •
4 VoltPhNV1 Ph-N Voltage V1 V
Unsigned
• • • • •
5 VoltPhNV2 Ph-N Voltage V2 V
Unsigned
• • • • •
6 VoltPhNV3 Ph-N Voltage V3 V
Unsigned
• • • • •
7 VoltPhNVn Ph-N Voltage Vn V
Unsigned
• • • • •
8 VoltPhPhU12 Ph-Ph Voltage
U12
V
Unsigned
• • • • •
9 VoltPhPhU23 Ph-Ph Voltage
U23
V
Unsigned
• • • • •
10 VoltPhPhU31 Ph-Ph Voltage
U31
V
Unsigned
• • • • •
11 CurrentI1 Current I1 A
Unsigned
• • • • •
12 CurrentI2 Current I2 A
Unsigned
• • • • •
13 CurrentI3 Current I3 A
Unsigned
• • • • •
14 CurrentIn Current In A
Unsigned
• • • • •
15 CurrentInba Current Inba %
Unsigned
• •
16 CurrentIdir Current Idir A
Unsigned
• •
17 CurrentIinv Current Iinv A
Unsigned
• •
18 CurrentIhom Current Ihom A
Unsigned
• •
19 CurrentInb Current Inb %
Unsigned
• •
20
PowerApparentNom Nominal
Apparent Power
VA Unsigned
• •
21
TotalPowerActive Total Active
Power
W Signed
• • • • •
22
TotalPowerRActive Total Reactive
Power
VAr Signed
• • • • •
23
TotalPowerApparent Total Apparent
Power
VA Unsigned
• • • • •
24
TotalPowerFactor Total Power
Factor
- Signed
• • • • •
25
TotalPowerFactorType Total Power
Factor Type
- Unsigned
• • • • •
26
PowerActiveP1 P1 Active Power W Signed
• • • • •
27
PowerActiveP2 P2 Active Power W Signed
• • • • •
28
PowerActiveP3 P3 Active Power W Signed
• • • • •
29
PowerRActiveQ1 Q1 Reactive
Power
VAr Signed
• • • • •
