3. INSTALLATION

3.1-5

Securing the UPS in a 19" Rack

3.1-6

Rack Tray and Mounting Bracket for a 23" Cabinet

3.1-7

Securing the UPS in a 23" Rack

Mounting Bracket

M3 x6 Bracket Screws

Rack Tray

NOTE

Rails cannot be used for 23" cabinets. Confirm that you have a rack tray.
