socomec NETYS RT Options Guide

6
- Ref.: IOMNETRTXX03-XX 02
6
2
Close switches
C
in
, C
out
, D
in
, D
out
3
Switch on both UPSs.
Close switch B
4
Load supplied by UPS
in parallel/redundant
conguration
1
Close the MAINS
switch
Start-up.
by-PASS cONNEcTION OF UPS IN PArALLEL.
AC INPUT 230Vac 50/60Hz
L N
UPS OUTPUT
LINE BREAKER
230Vac 63A
UPS1 BREAKER 230Vac 63A
INPUT OUTPUT
UPS2 BREAKER 230Vac 63A
INPUT OUTPUT
BYPASS BREAKER
230Vac 63A
TO UPS1
LN
L N
TO UPS1
230Vac 50/60Hz
TO UPS1 OUTPUT
L N
TO UPS2
230Vac 50/60Hz
TO UPS1 INPUT
TO UPS2 OUTPUT
AC OUTPUT 230Vac 50/60Hz
LN
TO UPS2 INPUT
PARALLEL
TO UPS2
PARALLEL
L N
155 DRWNETRT-XX
B
A
D in
C out
C in
D out
Legend
A BY-PASS switch
B UPS OUTPUT Line breaker
Cin UPS1 INPUT switch
Cout UPS1 OUTPUT switch
Din UPS2 INPUT switch
Dout UPS2 OUTPUT switch
154 DRWNETRT-XX
C in
C out
D in
D out
A
B
UPS1 UPS2
C in
C out
D in
D out
UPS1 UPS2
UPS1
LOAD
UPS2
UPS1 UPS2
B
156 DRWNETRT-XX 151 DRWNETRT-XX 157 DRWNETRT-XX
LOAD
MAINS
LOAD
MAINS
LOAD
MAINS

socomec NETYS RT Specifications

General

Technology	On-Line Double Conversion
Frequency	50/60 Hz
Battery Type	Sealed Lead-Acid (SLA)
Communication Ports	USB, RS232
Waveform	Sinewave
Operating Temperature	0 to +40 °C
