1.4. System Application
SNMP CARD is a communication interface between STATYS XS and the network. SNMP CARD
supports two kinds of protocol – SNMP and HTTP for user access. Through the SNMP NMS
and Web Browser, user can obtain the STATYS XS status, issue commands to STATYS XS and
setup the SNMP CARD through the network.

User’s
computer
STATYS XS
SNMP Card
NMS
Work staƟon
or web
Ethernet
Ethernet
Remote view
tŽƌŬƐƚĂƟŽŶ
Remote view
tŽƌŬƐƚĂƟŽŶ
Remote view
tŽƌŬƐƚĂƟŽŶ
Figure 1-2 SNMP CARD System Application Diagram
