SNMP CARD II - SOCOMEC
2. CONNECT SNMP CARD TO THE NETWORK
2.1. What you need
To install SNMP CARD on a network and change its default confi guration, you need a worksta-
tion running Microsoft Windows. If you are using dynamic IP addressing, all you need is a work-
station with a Web Browser.
2.2. Hardware Installation
1. Mount the SNMP CARD to SNMP CARD bracket provided.
2. Insert the SNMP CARD into the STATYS XS external communication slot. (Figure 2.1)
3. Tighten the screws of the SNMP CARD bracket.
Figure 2-1 SNMP CARD Installation
2.3. SNMP Card Confi guration
Upgrade tool
1. Copy the Upgrade utility to the desktop 2. Click Discover to search SNMP card IP address
