SNMP CARD II - SOCOMEC
2.4. SNMP CARD Confi guration through TELNET command
4. Make sure that you have a TCP/IP network already installed.
5. Run command shell
6. SNMP CARD will initially try to acquire an IP address from the DHCP network service, if
available on the network.
7. Type “Telnet <IP address obtained from DHCP>” and press enter.
8. If DHCP network service is not available on the network, contact your network administrator
to get an IP address for you workstation that has the same network’s address as the SNMP
CARD’s default IP address. The SNMP Card default IP address is 172.17.XXX.ZZZ where
XXX and ZZZ is the last two pairs of the MAC address in decimal located on the SNMP
CARD.
9. Type “Telnet 172.17.XXX.ZZZ” command and press enter. Password is admin.
2.5. SNMP CARD Confi guration through a Web Browser
HARDWARE PREPARATION OF SNMP CARD
1. Procure a workstation with Ethernet card and Web Browser installed.
2. Connect the network cable (twisted-pair cable) from the workstation’s LAN port to an active
10/100-hub port.
3. Connect another network cable (twisted-pair cable) from the SNMP CARD LAN port to an
active 10/100-hub port.
4. Set the SNMP CARD DIP-switches, the switches 1 and 2 are OFF.
5. Turn on the STATYS XS and wait for SNMP CARD to boot up (around 90 seconds).
