 Only qualified personnel should install the system according to current laws
in the country of installation.
 Keep all packaging (plastic bags, expanded polystyrene etc.) away from the
reach of children.
 Do not expose the cooler to direct sunlight and, to maintain performance,
we recommend you do not install the system in environments where the
temperature can exceed 32°C.
Surface treatment
Warning Before any cleaning procedure, switch off the cooler and disconnect
it from the main socket
Warning Do not use solvents or abrasive detergents.
A damp soft cloth will suffice
Cooler description
JUMBO 13 is a remote cooler that refrigerates and carbonates water from the mains.
It is possible to connect to the cooler an insulated “python” tube ( 2 ways: made of
two tubes, one in which refrigerated water flows and one in which carbonated water
flows, combined with 2 cooling water recirculation tubes) to supply a tower or a water
dispensing system.
Technical specifications
Power voltage
230 V ± 10%
Frequency
50 Hz
Compressor
1/4 hp
Absorbed power
575W
Absorbed current
3.22A
Pressure of water from the mains (water
inlet)
> 0.2 MPa (> 2 bar), < 0.4 MPa (< 4 bar)
CO 2 pressure
> 0.25 MPa (> 2,5 bar), < 0.45 MPa (< 4.5
bar)
Dimensions L x D x H
268.5 mm x 468 mm x 477 mm
Weight (empty)
28 Kg
Warning: during production the above data can vary of +/- 10%
