Sofar solar HYD 10K-20KTL-3PH User Manual (English)

Questions and Answers:

W
William WernerAug 2, 2025
Why does my Sofar solar HYD 10K-20KTL-3PH show a GridOVP error?
- D
  Denise CrawfordAug 2, 2025
  If the Sofar solar Inverter displays a GridOVP alarm occasionally, it might be due to temporary electric grid issues. The inverter should automatically resume normal operation once the grid stabilizes. However, if the alarm appears frequently, verify that the grid voltage and frequency are within the acceptable range. If they are, inspect the AC circuit breaker and the inverter's AC wiring. If the grid voltage or frequency is consistently outside the acceptable range and the wiring is correct, and the alarm persists, contact technical support to adjust the grid over-voltage, under-voltage, over-frequency, and under-frequency protection settings after approval from your local electrical grid operator.
S
Sean LucasAug 6, 2025
What to do if my Sofar solar Inverter displays a GFCI error?
- T
  Timothy PittmanAug 6, 2025
  If you see a GFCI error on your Sofar solar Inverter, switch it OFF and wait for 5 minutes. Then, switch it back ON to see if the problem is resolved. If the error continues, contact technical support for assistance.
N
Nicholas EatonAug 10, 2025
How to fix OverTempDerating error on Sofar solar HYD 10K-20KTL-3PH?
- G
  George NavarroAug 10, 2025
  If your Sofar solar Inverter is showing an OverTempDerating error, ensure that the unit is not exposed to direct sunlight. Relocate the inverter to a cooler, well-ventilated area, ensuring it is mounted vertically and that the ambient temperature remains below the inverter's maximum temperature limit.
S
Stephanie WrightAug 14, 2025
What to do if my Sofar solar HYD 10K-20KTL-3PH Inverter displays TempFault_Bat?
- N
  nicolelindseyAug 14, 2025
  To address a TempFault_Bat error on your Sofar solar Inverter, make sure it is installed away from direct sunlight. The inverter should be placed in a cool, well-ventilated environment, mounted vertically, and the ambient temperature must be below the inverter's temperature limit.
A
Amber StantonAug 18, 2025
How to resolve PvConfigError on Sofar solar HYD 10K-20KTL-3PH?
- C
  Carl HarrisonAug 18, 2025
  To resolve a PvConfigError on your Sofar solar Inverter, check the inverter's PV input mode settings (parallel/independent mode). Change the PV input mode if it is incorrect.
J
Jeffrey JonesAug 23, 2025
How to fix PEConnectFault on Sofar solar HYD 10K-20KTL-3PH?
- C
  Christina GriffinAug 23, 2025
  To solve the PEConnectFault issue on your Sofar solar Inverter, check the AC output PE wire to ensure it is properly grounded.
M
mwestAug 27, 2025
What should I do if my Sofar solar Inverter shows an IsoFault error?
- R
  Ryan RamosAug 27, 2025
  To address an IsoFault error on your Sofar solar Inverter, check the insulation resistance between the photovoltaic array and ground. If a short circuit is detected, repair the fault immediately.
