example).Start with battery 1 and work your way up to battery n.
Battery Type
Type of band
communication protocol
Lead acid or no protocol
type
1.Battery Address
1.Battery Capacity
2.Battery Charge Current
Limit
2.Battery Nominal Voltage
3.Battery Discharge
Current Limit
3.Battery Cell Type
4.Battery DOD(EOD)
4.Battery Charge Current
Limit
5.Battery Discharge Current
Limit
6.Battery DOD(EOD)
Table 6-2 Default values for other Settings
Item
The default state
Energy Storage Mode
Self-use mode
EPS Mode
Disable
Anti Reflux
Disable
IV Curve Scan
Disable
Logic interface
Disable
6.3. Menu
Fig 6-1. Main interface
In the main interface, press “Down” button to enter grid/battery parameters
page.
Main interface
Down↓
Grid Output Information
Grid(V) .........................***.*V
AC Current ...................**.**A
Frequency.....................**.**Hz
