Sofirn C8L - ANSI;NEMA FL1 Chart; Specifications; Power Indicator

ANSI/NEMA FL1 Chart
Mode
Eco
Low
Medium
High
Turbo
Strobe
SOS
Beacon
Luminous
Flux
8 Lm
100 Lm
500 Lm
1300 Lm
3100 Lm
3100 Lm
500 Lm
3100 Lm
Runtime
220h
26h
6h58min
2h28min
1h45min
-
-
-
Distance
27 m
98 m
216 m
354 m
531 m
-
-
-
Intensity
182 cd
2308 cd
11675 cd
31275 cd
70500 cd
-
-
-
Impact
resistance
1 meter / 3.28 feet
Waterproof
IPX-8 (up to 2 meter under water, not for diving)
Beam Angle
26 degrees for throw, 82 degrees for flood
Note
The above mentioned parameters are based on tests according to international flashlight testing
standards (ANSI/NEMA FL1) using one 4800mAh 21700 Li-ion battery in our laboratory. Results may
vary with different battery or under different environmental conditions. Operation temperature is 0°C
- 40°C.
Specifications:
 1 X CREE XHP50D-HI LED

Working Voltage: 3.0V - 4.2V
 Battery Options: One 21700 Li-ion battery or one 18650 Li-ion battery
 Dimension: 156mm (length) × 46.5mm (head diameter)

Weight: 151 (without battery)
 Flashlight body: Aerospace grade 6061 grade aluminum alloy, CNC manufactured to hard-anodized
anti-abrasive finish to get solid built body, anti-crash geometry and better heat exchange.
 Toughened mineral glass lens

IPX8 Waterproof
 USB Type-C Charging
 Mode Memory: memorizes the last brightness level used in the general modes (Eco/Low/Med/High)
 Advanced Temperature Regulation (ATR) technology: ATR will adjust the brightness level
automatically when the driver temperature reaches 50
℃
(122 °F) to prevent overheating
Power Indicator:
The LED indicator in the side switch shows the power status for 5 seconds after turning C8L on.
Green = remaining battery power is good.
Red = remaining battery power is poor (less than 30%).
Flashing Red = critical power, replace or recharge battery as soon as possible.
