Sofirn IF23 - Sofirn IF23 Specifications; Emitter and Battery; Performance and Material; Physical and Water Resistance

(SPOTLIGHT)
BEAM
DISTANCE
(FLOODLIGH
T)
3m
5m
13m
21m
39m
-
-
-
PEAK
INTENSITY
(SPOTLIGHT)
2.58 cd
425 cd
2092.5 cd
6375 cd
15275 cd
-
-
-
PEAK
INTENSITY
(FLOODLIGH
T)
2.6 cd
7.4 cd
44.3 cd
115.5 cd
380 cd
-
-
-
IMPACT
RESISTANCE
1m / 3.28ft
WATER
RESISTANCE
IP68 (up to 2 meter under water, not for diving)
NOTE
The above mentioned parameters are based on tests according to international flashlight testing standards
(ANSI/NEMA FL1) using one 4000mAh 21700 battery. Results may vary with different battery or under different
environmental conditions.
Specifications
 Emitter: 1* XHP50B, 20* CSP1313(13-3A3-I1-90-B2-BD-GR), 10* Color LEDs(JF-387F-Y)
 Battery Option: 1x 21700 battery
 Working Voltage: 2.7V-4.2V
 Mode Operation: Side e-switch
 Standby Drain: ≤150uA
 Input: Type-A to type-C 5V 3A
 Maximum Charging Current: 3A
 Material: A6061-T6 aluminium alloy
 Water Resistance: IP68 waterproof
 Reflector Type: Orange peel reflector
 Lens Type: Toughened glass lens
 Dimension: 27.5* 30.05* 120.5mm
 Weight: 125g(without a battery)
 Spotlight beam angle: 15°, floodlight beam angle: 85°
 Reverse polarity protection from improper battery installation.
 Low Battery Level Warning: When the battery voltage is low, the LED indicator will flash red. Please
recharge the battery.
Battery Options
Battery Type
Dimension & Quantity
Rechargeable li-ion battery
1 x 21700 battery
