GCM General Control Module
9
LCD Panel
The LCD panel will display various status information, such as the connection status to
the host, and various diagnostic functions.
If the LCD panel is difficult to read, adjust the contrast using the potentiometer at the
upper right section of the GCM.
MAC Address
When configuring an iSTAR Controller, it is necessary to supply the MAC address of
the NIC card that is connected.
The MAC address for the on-board 10BaseT NIC is displayed on a sticker just left of
the Power LED.
If a PCMCIA NIC card is used, the MAC address will be provided by the manufacturer.
