4. Input the elements for the next curve.
Input the parameter A1, parameter A2
and radius R for the next curve. The
offset is automatically set.
• The offset is not displayed if "Next
BP" described in "25.8.8 Setting
parameters" is set to "IP".
• When [IP] is pressed, the intersection
angle, turning direction, the lengths
of the curves between IP1-IP2 and
IP2-IP3 are calculated from the BP,
the IPs and the curve elements, and
the results are displayed. After
checking the results, press [OK].
5. Continue inputting the elements for
the following curves.
Input the elements for the following
curves in the same manner as shown
in steps 3 and 4.
6. Quit inputting the curve elements.
When input of the elements for all
curves is completed, press [OK]. The
screen will return to <Curve Element
Setting>.
25.8.3 Displaying curve properties
It is possible to check the curve properties set in “25.8.2 Inputting Curve
Elements”. To make alterations, follow the procedure described in “25.8.2
Inputting Curve Elements”.
• The curve property data will be displayed in ascending order of curve number.
PROCEDURE
1. Input the IPs.
C“25.8.1 Inputting IPs (Intersection
Points)”
Element2
Para A1
Para A2
<Null>
<Null>
Radius
St. ofs
195.386m
50.000m
OKI P
To Next Page
