Sol-Air F2000 - Specifications and Parts; System Specifications; Parts List

F 2 0 0 0 O P E R A T I O N S & M A I N T E N A N C E
Version 1.5 (121506) 10
1010
10
S O L - A I R F 2 0 0 0 S P E C I F I C A T I O N S
Dimensions:
14” x 20” x 30”
(35.6 x 50.8 x 76.2 cm)
Weight:
75 lbs (34.1 kg)
Power Requirements:
120V, 4.0A
Starting:
Selector Switch, with indicator light
Fan Control:
Variable Speed Control 100 to 1000 cfm
Meter:
1/10 Quartz Hour Meter
P A R T S L I S T
P A R T D E S C R I P T I O N P A R T N U M B E R
10" Dual Zone UV U-Lamp
30-0011
Electronic Ballast
30-0006
Fan Speed Control Switch (Variable Speed Switch)
32-0006
Quartz Hour Meter
32-0009
ON / OFF Switch (2 Position)
32-0001
4 Amp Fuse (Slo-Blow)
30-0001
6 Amp Fuse (Slo-Blow)
30-0002
