Solar MPPT-10 User Manual

10
temperature, cable voltage drop and also cable material. We suggest
customer to control the maximum battery voltage loss under 1.5%, and control
the maximum voltage loss of solar panels under 2.5%.
The following is the cable length between controller and battery, and the
suggested copper cables:
Cable
Length
Cable Size
in mm
2
Cable Size
in AWG
Voltage Loss
at 10A
(a pair)
Battery Voltage Loss
12V
24V
48V
1m
2.5mm
2
#13 AWG
0.14V
1.2%
0.60%
0.30%
2m
4mm
2
#11 AWG
0.18V
1.5%
0.75%
0.38%
4m
6mm
2
#9 AWG
0.24V
2.0%
1.0%
0.50%
Table 3-4: Cable Length & Cable Voltage Drop
The following is the cable length between solar panels and controller, and
also the suggested copper cables:
Cable
Length
Cable
Size in
mm
2
Cable Size
in AWG
Voltage Loss
at 10A
(a pair)
Solar Panels
Voltage Loss
17V
34V
68V
2m
4mm
2
#11 AWG
0.18V
1.1%
0.53%
0.26%
4m
6mm
2
#9 AWG
0.24V
1.4%
0.71%
0.35%
8m
10mm
2
#7 AWG
0.29V
1.7%
0.86%
0.43%
Table 3-5: Cable Length & Cable Voltage Drop
3.4 Over Current Protection
The electrical equipment used in power circuit must be equipped with over
current and short-circuit protection devices, and there is no exception for
MPPT-10 controller. The controller adopts in the design of common positive
pole inside. We suggest users to install over-current breaker or fuse on the
negative loop of solar panels input, and also the negative loop of battery output.
The capacity of over-current breaker or fuse is 1.25 times of the rated current.
3.5 Lightning Protection
It is the same as other electrical devices that MPPT-20 controller will be
damaged by lightning. The controller has limited surge absorption capacity.
We strongly suggest users to install lightning surge absorption devices to
increase the reliability of the system.
