Solar MPPT-10 User Manual

17
7. Technical Data
Model
MPPT-10
Input
Maximum PV voltage
≤70V
MPPT voltage range
12V~70V (12V)
24V~70V (24V)
Output
System voltage
12V (24V)
Maximum battery voltage
16V (32V)
Maximum charging current
10A
Maximum load current
10A
Own consumption
≤15mA
Charging control mode
3-stage (Bulk, Absorption, Float)
Float charge
13.8V (27.6V)
Absorption charge
14.4V (28.8V), for 2 hours
Load disconnection (LVD)
11.5V (23.0V)
Load reconnection (LVR)
12.6V (25.2V)
Temperature
compensation
-4mV/ cell/ °C
Battery type
Lead acid (GEL, AGM, Flooded)
Other
Maximum efficiency
97%
Human interface
LEDs, button
Cooling style
Passive cooling
Maximum wire size
6 mm
2
Ambient temperature
range
-10 to +50 °C
Storage temperature
range
-30 to +80 °C
Humidity
0 to 90%, no condensation
Dimensions
92.5 x 188 x 55.3 mm
Weight
0.46 Kg
Grounding
Positive grounding
Degree of protection
IP32
Note: Techni c al data at 25 °C / 77 °F
