Note: Please switch off the breakers of battery, solar
panels array before installing the controller. Do not touch
the positive and negative pole of solar panels or battery
at the same time when installing, otherwise you have the
risk of electrical shock.
A. Mount the controller on the wall and fasten the screws.
B. Check whether the battery voltage and solar panels array voltage is
within the requested range.
C. Switch off the over-current breaker or fuse of the battery, solar panels
array and load.
D. Wiring.
(1) Connect the battery with the battery terminal on the controller by
cables and fasten the screws.
(2) Connect the load with the load terminal on the controller by cables and
fasten the screws.
(3) Connect the solar panels array with the solar panel terminal on
controller by cables and fasten the screws.
E. Switch on the breaker or fuse of the battery, then the 3 indicators indicate
the system status. Switch on the breaker or fuse of the load. (more
information about the indicators see Chapter 5.2 and 5.3)
F. Switch on the breaker or fuse of the battery, then the controller starts to
charge the battery.
5.1 Button Function
There is only one concealed button on the controller, which used to restart
the load when the controller is in overload protection state. The second
function of the button is to control the load. Press the button and hold about 3
seconds, then the load will be switched off. This can also switch on the load.
To Next Page
