Using a Paper Template
Fill out the Physical Layout Template (downloadable from the SolarEdge
website http://www.solaredge.com/files/pdfs/physical-layout-
template.pdf)using the detachable 2D barcode stickers on each power
optimizer. Once the form is completed, use the Mapper to scan the 2D
codes and create the map in the monitoring platform. Optionally, you can
send the sticker sheet to SolarEdge Support for physical layout creation.
Chapter 5: Commissioning the Installation 43
Three Phase System Installation Guide MAN-01-00057-4.1

SolarEdge SE10k Specifications

General

AC Output Power	10000 W
Maximum Efficiency	98.3%
Cooling	Natural Convection
Protection Rating	IP65
Rated AC Power	10000 W
Max. DC Power	13500 W
CEC Weighted Efficiency	97.5%
Topology	Transformerless
Number of MPP Trackers	2
Warranty	12 years
Operating Temperature Range	-25°C to 60°C
Communication Interfaces	RS485, Ethernet
DC Overvoltage Protection	Type 2
