CPU: The communication board firmware version
Country: the current country setting
Server Communication Status
S e r v e r : L A N < S _ O K >
S t a t u s : < O K >
x x x x x x x x
< E R R O R M E S S A G E >
NOTE
If the connection method is CDMA (referred to as "Cellular" in the status
screens)or GSM, the server screen is replaced with the Cellular or GSM status
screens (see
Status Screens - Operational Mode
on page 57 and
GSMStatus
on
page 61).
Server: The method of connection to the SolarEdge monitoring platform.
S_OK: The connection to the SolarEdge monitoring platform is successful
(should appear only if the inverter is connected to the server).
Status: Displays OK if the inverter established successful connection and
communication with the specified server port/device (LAN, RS485, Wi-Fi or
ZigBee Plug-in).
xxxxxxxx: Eight-bit Ethernet communication connection status: A string of 1s
and 0s is displayed. 1 indicates OK, 0 indicates an error. For a list of the possible
errors and how to troubleshoot them, refer to
Troubleshooting Communication
on page 80
Error message, according to failure. Refer to
http://www.solaredge.com/sites/default/files/se-inverter-installation-
guide-error-codes.pdf.
IP Status
This screen describes the Ethernet configuration: IP, Mask, Gateway and MAC address
(Media Access Control) of the Inverter.
I P 1 9 2 . 1 6 8 . 2 . 1 1 9
M S K 2 5 5 . 2 5 5 . 2 5 5 . 0
G W 1 9 2 . 1 6 8 . 2 . 1
M A C 0 - 2 7 - 0 2 - 0 0 - 3 9 - 3 6
-Three Phase System Installation Guide MAN-01-00057-4.1
60 Status Screens - Operational Mode
