Reporting and Monitoring Installation Data
NOTE
Monitoring the site requires connecting the inverter to the monitoring
platform, using any of the wired or wireless options available from
SolarEdge. Refer to
Setting Up Communication
on page 61.
The Monitoring Platform
The monitoring platform provides enhanced PV performance monitoring and yield
assurance through immediate fault detection and alerts at the module , string and
system level.
Using the platform, you can:
View the latest performance of specific components.
Find under-performing components, such as modules, by comparing their
performance to that of other components of the same type.
Pinpoint the location of alerted components using the physical layout.
The monitoring platform enables accessing site information, including up-to-date
information viewed in a physical or logical view:
Logical Layout: Shows a schematic tree-layout of the components in the
system, such as: inverters, strings, modules, meters and sensors, as well as
their electrical connectivity. This view enables you to see which modules are
connected in each string, which strings are connected to each inverter, and
so on.
Physical Layout: Provides a bird's eye view of the actual placement of
modules in the site, and allows pinpoint issues to the exact location of each
module on a virtual site map.
If you do not report the mapping of the installed power optimizers, the monitoring
platform will show the logical layout indicating which power optimizers are connected
to which inverter, but will not show strings or the physical location of power
optimizers.
The monitoring platform includes a built-in help system, that guides
you through the monitoring functionality.
For more information, refer to https://www.solaredge.com/products/pv-
monitoring#/.
