19.01-17
SolaStat-Plus Specifications.
Power Supply.
Supply Voltage. -H 85~264Vac/dc (standard model)
-M 22~85Vdc. (Must be specified at time of ordering.)
-L 10~28Vac/dc. (Must be specified at time of ordering.)
Max power usage. 5VA + external loads.
Relay Outputs. -Three Options can be ordered. (All ratings at 240Vac.)
-1. 1 x 1hp motor.
10A resistive flexible wiring.
-2. 2 x 1hp motor. 1hp combined load.
10A resistive combined load flexible wiring.
Sensors.
Display range -20 ~ +140C
Control Range -40 ~ +150C
Stainless steel tip -40 ~ +150C; 6mm diameter x 30mm
PVC Sensor cable -40 ~ +105C; 4mm diameter, UV resistant. (Standard Models)
Silicon Sensor Cable -40 ~ +150C; 4mm diameter, UV resistant. (Special Order)
Accuracy +/-1C @ 25C
Adjustable Values Range. (Adjustable in programming mode.)
Pump-On 2~21C (Roof – Inlet sensor).
Pump-Off 1~20C (Roof – Inlet sensor).
Top Out Protection: 1~120C with -2C hysteresis or OFF.
Frost Protection: 1~10C with +2C hysteresis or OFF.
HWC Adjustable Values Range. (Adjustable in programming mode.)
Default HWC state: ON/OFF.
Holdoff Timer: 1~23 hours or Thermostat Mode or Reheat Mode.
Reheat lower (set): 1~70C or OFF.
Reheat upper (reset): 2~90C or OFF.
EMC and Safety Compliances.
Emissions: EN 55022-A, CTick.
Immunity: EN 50082-1.
Safety Compliance: EN 60950, CTick.
General Specifications. (Unless otherwise stated in other input specifications.)
Operating Temperature: 0~60C
Operating Humidity: 90% RH Max. Non-Condensing
Enclosure Construction Polycarbonate - Impact Resistant
UL94 V-2 Non Burning, UV Stabilized
Water resistant or rear entry option available.
Dimensions L=167, W=142, H=40mm, excluding glands and cables
Weight. Standard model + sensors + packaging = 1200grams
Product Liability. This information describes our products. It does not constitute guaranteed properties
and is not intended to affirm the suitability of a product for a particular application. Due to ongoing research
and development, designs, specifications, and documentation are subject to change without notification.
Regrettably, omissions and exceptions cannot be completely ruled out. No liability will be accepted for
errors, omissions or amendments to this specification. Technical data are always specified by their average
values at 25C and are based on Standard Calibration Units at 25C, unless otherwise specified. Each
product is subject to the ‘Conditions of Sale’.
