2 Safety
2.1 Safety Instructions
For safety reasons, installers are responsible for familiarizing themselves with the
contents of this manual and all warnings before performing installation.
2.1.1 General Safety Precautions
Observe the following precautions:
Ÿ Risks of explosion
– Do not subject the battery module to strong impacts.
– Do not crush or puncture the battery module.
– Do not dispose of the battery module in a fire.
Ÿ Risks of fire
– Do not expose the battery module to temperatures in excess of 60°C.
– Do not place the battery module near a heat source, such as a fireplace.
– Do not expose the battery module to direct sunlight.
– Do not allow the battery connectors to touch conductive objects such as
wires.
Ÿ Risks of electric shock
– Do not disassemble the battery module.
– Do not touch the battery module with wet hands.
– Do not expose the battery module to moisture or liquids.
– Keep the battery module away from children and animals.
Ÿ Risks of damage to the battery module
– Do not allow the battery module to get in contact with liquids.
– Do not subject the battery module to high pressures.
– Do not place any objects on top of the battery module.
T-BAT SYS-HV can be used only in the household energy field. It is not allowed to
be used in other industries, such as the medical equipment and automotive
application.
Warning!
Please don't crush or impact the battery, and always dispose it
according to the safety regulation.
2.1.2 Explanation of Symbols
This section gives an explanation of all the symbols shown on the T-BAT system
and on the warning label.
Caution!
If the battery is not installed within one month after receiving the battery, the
battery must be charged for maintenance.
Lithium ion Rechargeable Battery System
Product Name: T-BAT SYS-HV
Max.Charge/Discharge Current: 30A
Ingress Protection: IP 55
Operating Temperature: 0~+45℃
Storage Temperature: -20~+50℃
SolaX Power Network Technology (Zhejiang) Co., Ltd
ADD: No.288 Shizhu Road, Tonglu Economic Development Zone,
Dongxing District, Tonglu City, Zhejiang Province, China.
TEL: +86 571 5626 0011 E-mail: info@solaxpower.com
Made in Chi na
www.solaxpower.com
612 .011 75.0 0
Rated Capacity: 56Ah
Model No./Nominal Voltage/Rated Capacity
T-BAT H 5.6/100.8Vdc/5.6kWh INR/27/66/[(14P28S)1S]M/-10+40/90
T-BAT H 11.2/201.6Vdc/11.2kWh INR/27/66/[(14P28S)2S]M/-10+40/90
T-BAT H 16.8/302.4Vdc/16.8kWh INR/27/66/[(14P28S)3S]M/-10+40/90
T-BAT H 22.4/403.2Vdc/22.4kWh INR/27/66/[(14P28S)4S]M/-10+40/90
Rated Capacity: 40Ah
Model No./Nominal Voltage/Rated Capacity
T-BAT H 4.0/100.8Vdc/4.0kWh INR/27/66/[(10P28S)1S]M/-10+40/90
T-BAT H 8.0/201.6Vdc/8.0kWh INR/27/66/[(10P28S)2S]M/-10+40/90
T-BAT H 12.0/302.4Vdc/12.0kWh INR/27/66/[(10P28S)3S]M/-10+40/90
T-BAT H 16.0/403.2Vdc/16.0kWh INR/27/66/[(10P28S)4S]M/-10+40/90
SN:
