SolaX Power X1-2.5-S-D User Manual

5. Installation
5. Installation5. Installation
5.1 Check for Transport Damage
5.2 Packing List
5.3 Installation Precaution
Make sure the inverter is intact during transportation. If there are some visible
damages, such as cracks, please contact your dealer immediately.
Please avoide direct sunlight, rain exposure, snow laying up during installing and
operating.
Available Space Size
X1 Series inverter is designed for outdoor installation (IP 65).
Make sure the installation site meets the following conditions:
Not in direct sunlight.
Not in areas where highly flammable materials are stored.
Not in potential explosive areas.
Not in the cool air directly.
Not near the television antenna or antenna cable.
Not higher than altitude of about 2000m above sea level.
Not in environment of precipitation or humidity (＞95%).
Be sure the ventilation is good enough.
The ambient temperature in the range of -20℃ to +60℃.
The slope of the wall should be within ±5°.
Open the package and fetch out the product, check the accessories at first. The
packing list shows as below.
Object
X1 series inverter1A
B
A
H
B C D E
F
G
I J K(optional)
C
D
E
F
G
H
I
J
K
2
1
3
3
1
1
1
1
1
DC connector
AC connector
Expansion tube
Expansion screw
Cross recessed screw
Product manual
Warranty card
Plug and Play Pocket WiFi (optional)
Quantity
Description
Warran ty
Regis tratio n
Form
For Customer (Compulsor y)
For Installer
Name
Product Serial Number
Date of Commissioning
Installation Company Name
Installer Name
Contract’s Licence Number
Phone Number
Address
State
Country
Zip Code
Email
Please note that this is NOT an Official Warranty Certificate.
614.00002.06
Module Brand
System Size
Number of String Number of Panel Per String
Battery Type
Brand
Number of Battery Attached
Battery ( If Any )
Module ( If Any )
Date of Delivery Signature
Online warranty registration is available at http://solaxpower.com/warranty/
Further information for the warranty regulations and liabilities will be listed on the
back of official warranty certificate issued by SolaX Power, or please visit our official
website:www.solaxpower.com for more details.
Room 220, West Buliding A Sci. and Tech Park of Zhejiang University
No.525, Xixi Road, Hangzhou Zhejiang Province, China 310007
Tel: +86 571 56260011 Fax: +86 571 56075753 Email: service@solaxpower.com
Position Min.size

30cm 30cm
Left
30cm
30cm
30cm
30cm
30cm
Right
Top
Bottom
Front
Table Available Space Size
30cm
30cm
1
2
3
4
X1
1
2
3
4
X1
1312
Ring terminal ×1
Quick installation guide×1
